40 Feet BESS Container layout
Features and functions：
Advanced three-level technology, max. efficiency 99% Effective forced air cooling, 1.1 overload capacity, no derating up to 55°C，Various charge and discharge mode, flexible for battery configuration
Integrated current & voltage monitoring function for online analysis and fast trouble shooting
Modular design and all components front accessible, easy for maintenance，
Integrated auxiliary power supply panels for external devices
Typical applations: peak shaving,energy shifting,frequency regulation,capacity firming Bidirectional power conversion system with full four- quadrant operation
Battery charge & dis-charge management , black start function and VSG integrated
Compliance with IEC 61727, IEC 62116, SGSF Dynamic grid voltage and frequency support L/HVRT, L/HFRT, soft start/stop, specified power factor control and reactive power support
We can provide:
1. All in One integrated design ESS:
Capacity from 3.6kwh to 20kwh basic model. If want larger just parallel. It doesn’t need inverter or other parts anymore, our product built-in all already.
2. Separated solar power storage system from 3.5kwh to 54kwh.
3. Single Battery packs: basic model 2.4kwh/3.6kwh/4.8kwh each pack.
4. EPC solar storage project whole solution，from 20kwh-20MWh.
